Use of the Arisaka Optic Leveler makes the assumption that the scope’s turret cluster and reticle are aligned, which may not be the case with poor quality scopes. Tighten the other ring according to the torque specifications provided by the ring/mount manufacturer. Tighten one scope ring according to the torque specifications provided by the ring/mount manufacturer.ħ. Gently apply pressure to the wedge until the scope rotates and is leveled.ĥ.

keymod accessories torque specs

Insert the leveler wedge into the slot on the base from the side until it contacts the bottom of the turret cluster.Ĥ. The raised recoil lug protrudes into the slot. Finally tighten the two screws for a secured mount. The angled slot should be on the top side.ģ. KeyMod works like a Gorilla rack, the big part slides plugs into the 'Key hole' first, then the shoe shaped chamfered nut cams and clicks in place. Place the leveler base on the Picatinny rail or one-piece mount directly below the turret cluster of the scope. Tighten rings to remove slack, but leave loose enough that the scope can still be rotated by hand.Ģ. The leveler requires a flat surface directly below the turret cluster to function.ġ. Please note: some one-piece scope mounts like those made by Bobro may not have enough space, so be certain to check with your specific scope and mount. This product includes the leveler base and small wedge, which requires a space between the rail/mount and turret cluster from 0.190″ to 0.730″. This updated version includes an offset slot in the leveler base, which helps provide more leeway on one-piece scope mounts that have ramped surfaces, such as the Aero Precision Ultralite mounts. As the 11 degree ramped surfaces of the wedge and base engage, the top of the wedge rises upwards and contacts the turret cluster, automatically leveling it. The base plate sits on the Picatinny rail or one-piece mount just below the turret cluster of the scope, and then the matching wedge is inserted from the side. The Arisaka Optic Leveler is an inexpensive, easy-to-use tool for leveling scopes mounted in rings or one-piece mounts.
